Lagoon 421 - Generator; Battery Charger (Optional Extra); Inverter (Optional Extra)

LAGOON 421
6
ELECTRICITY
59
• SWITCHING ON DEVICES FUNCTIONING ON 110 V - 220 V
To use appliances that work on 110 V - 220 V (Washing machine,
Water maker, etc.), proceed as follows:
- Make sure that the appliances are OFF on the electrical panel.
- Switch to the 110 V - 220 V source ()start the generator or plug in-
tothe shore power supply.
- Select the proper source on the electrical panel for it to supply the
electrical panel.
- Switch on the circuit breaker for the appliance to be used (Washing
machine, Water maker, etc.) on the electrical panel.
Once the above has been carried out,turn on the appliance using its
own controls.
For air conditioning 110 V - 220 V, wait 10 to 15 seconds between
turning on each unit (in order to allow the generator to stabilize and
to deliver the necessary power for switching on).
• SWITCHING OFF DEVICES FUNCTIONING ON 110 V - 220 V
To turn off appliances functioning on 110 V - 220 V (Washing ma-
chine, Water maker, etc.), proceed as follows:
- Stop the apparatus using its own controls.
To stop 110 V - 220 V equipment wait 3 to 4 seconds after turning
off each device (in order to allow the generator to stabilize).
- Switch off the circuit breaker of the relevant apparatus on the elec-
trical panel.
- Turn the 110 V - 220 V source selector to OFF (generator or shore
power supply).
- Stop the generator or unplug the shore power supply.
• PROTECTION
Connect the metallic covers or boxes of the electric appliances that
are installed to the protective conductor of the boat (green conduc-
tor with yellow stripes).
The service compartment where the fuses are located is situated
behind the electrical panel. To access this area lift up the plate abo-
ve the electrical panel in order to unclip it (2 clips), then pull it to-
wards you to remove the plate from the end groove into which it is
fitted.
110 V - 220 V system
WARNING
Before turning the OFF V - 110 V source selector to 220, en-
sure that no other appliance is in use (danger of an electric
arc which can destroy the switch and damage the genera-
tor).
Technical room
ELECTRICITY
