LAGOON 421
ELECTRICITY
60
1 - Generator
2 - Sea water filter
3 - diesel filter
4 - Draining valve - Water-gas exchanger
5 - Starting - Generator
6 - Generator/shore commutator
7 - Battery - 50A
8 - Seawater inlet + Filter
9 - Battery switch
10 - Fuel supply valve
(Reference 4)
GENERATOR
