Parts List DFLUX1
Ref #
Part Number
Description
Qty
1
MDCDF15510-1
IMPELLER HOUSING
1
2
MDCDF15510-2
COLLECTION DRUM
1
3
MDCDF15510-3
INTAKE BARREL
1
4
MDCDF15510-4
CYCLONE FUNNEL
1
5
MDCDF15510-5
FILTER COVER PLATE
1
6
MDCDF15510-6
COLLECTION DRUM LID
1
7
MDCDF15510-7
HEX NUT 5/16-18
18
8
MDCDF15510-8
INLET ADAPTER 6" X 4" X 2
1
9
MDCDF15510-9
LEVER HANDLE
1
10
MDCDF15510-10
MOTOR 1.5HP 110V 1-PH
1
11
MDCDF15510-11
HEX NUT 5/16-18
43
12
MDCDF15510-12
HEX BOLT 5/16-18 X 1
4
13
MDCDF15510-13
RUBBER GASKET
1
14
MDCDF15510-14
PHLP HD SCR M5-.8 X10
3
15
MDCDF15510-15
Socket head cap screw M6 X 16
2
16
MDCDF15510-16
PADDLE HANDLE SPINDLE RETAINER
1
17
MDCDF15510-17
FILTER PADDLE HANDLE
1
18
MDCDF15510-18
FLANGE BOLT 5/16-18 X 1/2
8
19
MDCDF15510-19
FLANGE BOLT 5/16-18 X 3/4
60
20
MDCDF15510-20
PHLP HD SCR 3/16 X 3/8
2
21
MDCDF15510-21
PADDLE HANDLE SPINDLE
1
22
MDCDF15510-22
HEX BOLT M6-1 X 16
1
23
MDCDF15510-23
INLET ADAPTER CAP 4"
1
24
MDCDF15510-24
PHLP HD SCR 3/16 X 3/8
1
25
MDCDF15510-25
FLEX HOSE 7"
1
26
MDCDF15510-26
FOAM GASKET
1
27
MDCDF15510-27
DRUM WINDOW ACRYLIC
1
28
MDCDF15510-28
RIVET ALUMINUM
8
29
MDCDF15510-29
COLLECTION DRUM HANDLE
1
30
MDCDF15510-30
PHLP HD SCR 1/4-20 X 5/8
2
31
MDCDF15510-31
ACORN NUT 1/4-20
2
32
MDCDF15510-32
IMPELLER 12-3/4"
1
33
MDCDF15510-33
IMPELLER WASHER
1
34
MDCDF15510-34
CAP SCREW M6-1 X 30
1
35
MDCDF15510-35
COLLECTION DRUM GASKET
1
36
MDCDF15510-36
HOSE CLAMP 1-3/4"
2
37
MDCDF15510-37
VACUUM HOSE 1-1/2"
1
