3HP Mobile Dust Cyclone Manual
10
IN ALL CASES, MAKE CERTAIN THE RECEPTACLE IN QUESTION IS
PROPERLY GROUNDED. IF YOU ARE NOT SURE, HAVE A QUALIFIED ELECTRICIAN CHECK
THE RECEPTACLE.
220 VOLT Single-Phase Operation
The motor supplied with your machine is a 220 volt motor. It is shipped ready-to-run
for 220 volt operation.
FUNCTION
High frequency remote control switch
Hand held remote controller
OFF button ON button
*Remote set button
*Used to match up a new hand held
controller with the remote switch
ON/OFF Switch
Motor Cord
On board circuit breaker
Power Cord
