laguna MDCCF32201 - Part List

MDC CF32201 SPARE PARTS LIST REV. B
44
Part List
Ref No
Part Name Description Q’TY
1
MOTOR 3HP/220V/60Hz/1Phase
1
1A
MOTOR GASKET 1
2
MOTOR SUPPORT BASE 1
2A
HEX LOCK BOLT 5/16”*5/8”
12
2B
FLAT WASHER 3/8”*OD23*2t 8
2C
HEX BOLT 3/8”*1” 4
2D
HEX NUT 3/8”
4
2E
FLAT WASHER 3/8”*OD23*2t 4
2F
HEX BOLT 3/8”*1-1/4” 4
2G
SWITCH PLATE
1
2H
HEX BOLT 1/4”*3/4” 4
2I
FLAT WASHER 1/4”*OD19*1t 4
2J
LOCK WASHER 3/8”
4
2K
LOCK WASHER 3/8” 4
3
FAN Ø15.5” 1
3A
FLAT WASHER 5/16”*OD45*3t
1
3B
HEX BOLT 5/16”*3/4” 1
6
DUST CHUTE 1
6A
CANISTER COVER PLATE
1
6B
SHEET METAL THREAD BOLT 3/16”*1/2” 12
8
COVER PLATE 1
8A
SHEET METAL THREAD BOLT M4*12mm
4
9
TOP UPRIGHT SUPPORT TWO DOT 1
9A
HEX BOLT
5/16”*3/4”
12
