MDC CF32201 SPARE PARTS LIST REV. B
45
Ref No
Part Name Description Q’TY
9B
FLAT WASHER 5/16”*OD18*2t 12
9C
LOWER UPRIGHT SUPPORT TWO DOT 1
10
TOP UPRIGHT SUPPORT TWO DOT
1
10A
LOWER UPRIGHT SUPPORT TWO DOT 1
10B
HEX BOLT 5/16”*3/4” 6
10C
FLAT WASHER 5/16”*OD18*2t
6
10E
HEX BOLT 5/16”*1-3/4”
4
10F
FLAT WASHER 5/16”*OD18*2t 8
10G
HEX NUT 5/16”
4
10H
TOP UPRIGHT SUPPORT ONE DOT
1
10I
LOWER UPRIGHT SUPPORT ONE DOT 1
10J
UPRIGHT SUPPORT
REINFORCEMENT PLATE
3
10K
HEX BOLT 5/16”*3/4”
12
10L
FLAT WASHER 5/16”*OD18*2t 12
10M
FOOT PEDDLE BAR SUPPORT 2
10N
CARRIAGE BOLT 5/16”*1/2”
4
10O
FLAT WASHER 5/16”OD18*2t 4
10P
HEX NUT 5/16” 4
11
FOOT PEDDLE BAR
2
11A
PLUG 25*25 4
11B
HEX BOLT 3/8”*46mm 2
11D
MOVEABLE SUPPORT BRACE 208*20*21
2
11E
HEX LOCK NUT 3/8” 2
11F
SPRING Ø42*242L 2
11G
SKID BLOCK
2
