MDC CF32201 SPARE PARTS LIST REV. B
46
Ref No
Part Name Description Q’TY
11H
OCTAGON DRUM FOOT PEDDLE 520*226*350 1
11J
TOPPING
Ø24*30
2
11K
HEX BOLT M8*30mm
2
11L
HEX BOLT 3/8”*21mm 2
11M
HEX LOCK NUT 3/8” 2
11N
HEX BOLT 3/8”*1-1/2”
2
11O
HEX LOCK NUT 3/8”
2
12
TRIANGULAR SUPPORT PLATE 170*102*28 2
12A
HEX BOLT 5/16”*1-3/4”
4
12B
FLAT WASHER 5/16”*OD18*2t
8
12C
HEX NUT 5/16” 4
13
LOWER SUPPORT PLATE 30*28*98
2
14
PLASTIC BAG 55*95CM
3
15
BASE 1
15A
HEX BOLT 3/8”*3/4”
6
15B
FLAT WASHER 3/8”*OD23*2t
6
15C
SWIVEL CASTER 4” 4
15D
FLAT WASHER 5/16”*OD18*2t
16
15E
HEX BOLT 5/16”*3/4”
16
15F
HEX BOLT 5/16”*3/4” 4
15G
FLAT WASHER 5/16”*OD18*2t
4
15H
RIVET NUT 1/4”
2
15I
RIVET NUT 3/8” 6
15J
RIVET NUT 5/16”
20
16
OCTAGON DRUM FRONT PANEL
1
