MDC CF32201 SPARE PARTS LIST REV. B
47
Ref No
Part Name Description Q’TY
16A
FLAT HEAD PHILIP BOLT 5/16”*3/4” 4
16B
HANDLE 2
16C
FLAT WASHER 5/16”*OD23*2t
4
16D
HEX NUT 5/16” 4
16E
DRUM CASTER 3”*3/8” 4
16F
FLAT WASHER 3/8”*OD23*2t
8
16G
HEX NUT 3/8”
4
16H
OCTAGON DRUM BACK PANEL 1
16I
OCTAGON DRUM RIGHT PANEL
1
16J
OCTAGON DRUM LEFT PANEL
1
16K
LEFT SIDE PLATE 1
16L
RIGHT SIDE PLATE
1
16M
CARRIAGE BOLT 1/4”*1/2”
6
16N
FLAT WASHER 1/4”*OD19*2t 6
16O
HEX NUT 1/4”
6
16P
OCTAGON DRUM BASE PANEL
1
16R
WINDOW 1
16S
THREAD BOLT M4*12mm
40
16T
PLASTIC BOLT END CAP
43
17
INTAKE CYLINDER 9” 1
17A
HEX BOLT 5/16”*5/8”
4
18
CYCLONE BARREL
1
18A
HEX BOLT 5/16”*3/4” 12
18B
FOAM TAPE 3*6mm*10M
1
18D
CYCLONE FUNNEL
1
