laguna MDCCF32201 - Page 49

MDC CF32201 SPARE PARTS LIST REV. B
48
Ref No
Part Name Description Q’TY
18E
FLAT WASHER 5/16”*OD18*2t 12
18F
HEX BOLT 5/16”*3/4” 12
18G
FLAT WASHER 5/16”*OD18*2t
24
18H
HEX NUT 5/16” 12
19
OCTAGON DRUM LID 1
19A
HEX BOLT 5/16”*3/4”
8
19B
FLAT WASHER 5/16”*OD18*2t
16
19C
HEX NUT 5/16” 8
19D
PLUG MSP-16
1
19E
NUT AGL-16
1
19F
RUBBER GASKET 160CM 1
20
BAND CLAMP Ø400
1
20A
SPRING BAND CLAMP Ø400
1
22
ROTATION CRANK 1
22A
HEX BOLT 5/16”*3/4”
1
22B
FLAT WASHER 5/16”*OD30*3t
1
22C
GEAR
Ø20
1
22D
HEX BOLT 1/4”*3/4”
4
22E
FLAT WASHER 1/4”*OD19*2t
4
22F
BEARING
Ø70* Ø20.5*7t
1
22G
SEAL
1
23
ROTATION SHAFT
1
23A
HEX BOLT 1/4”*5/8” 8
23B
FLAT WASHER 1/4”*OD13*1t
16
23C
PADDLE
2
