laguna MDCCF32201 - Page 50

MDC CF32201 SPARE PARTS LIST REV. B
49
Ref No
Part Name Description Q’TY
23D
PADDLE BRANCH 2
23E
HEX LOCK NUT 1/4” 8
23F
ROTATION SHAFT CONNECTION
1
23G
HEX BOLT 5/16”*1-1/2” 1
23H
FLAT WASHER 5/16”*OD18*2t 2
23I
HEX LOCK NUT 5/16”
1
24
CANISTER FILTER Ø400*900L
1
24A
ROTATION SHAFT BASE 1
24B
SHEET METAL PHILIP BOLT 3/16”*3/4”
4
24C
HEX BOLT 5/16”*3/4”
1
24D
FLAT WASHER 5/16”*OD23*2t 1
24E
FOAM TAPE 3*25mm*1.5M
1
25
PLASTIC BAG
Ø40*60cm
3
27C
INTAKE MANIFOLD
Ø8” BY Ø4” X 3PORT
1
27A
SHEET METAL BOLT M4*12mm
3
32
FOLDABLE INSERT
1
33
FLAT HEAD BOLT 3/16”*1/2” 4
34
RIVET 3-2
6
34A
FLAT WASHER 1*8”*OD8*1t
6
34C
RIVET NUT 1/4” 8
34D
RIVET NUT 5/16”
18
35
ROUND HD BOLT 3/16”*1/2” 24
35A
NUT 3/16” 24
36
CONTROL BOX
44
RUBBER PLUG
1
45
RUBBER HANDLE FOR DRUM
INSERT
4
