LAI Games Lighthouse User Manual

Operator's Manual – Lighthouse
© LAI GAMES
Page 21
PRIZE ARM STATUS
Prize Arm Status adjustments P20 to P27 are used to disable Prize Arms that have
been removed to allow larger prizes to be dispensed from “Lighthouse”. Two
mirror blanking plates and four extra prize arm mounting holes have been
provided to allow the operator to arrange from one to four prize arm
configurations on each side of the LED display. Lighthouse comes with three
prize arms installed on each side as a default.
 P20 to 27 PRIZE ARM No.1 to 8 STATUS
(Adjustable ON or OFF)
These options are for enabling or disabling of
Prize Arm 1 to 8. The defaults as in the Table
Below.
Default Table
P#
Prize Arm No.
Default
P#
Prize Arm No.
Default
P20
Minor Arm 1
ON
P24
Minor Arm 5
ON
P21
Minor Arm 2
ON
P25
Minor Arm 6
ON
P22
Minor Arm 3
OFF
P26
Minor Arm 7
OFF
P23
Minor Arm 4
ON
P27
Minor Arm 8
ON
 P28 = NUMBER OF PRIZE ARM RE-TRIES
(Default 02) (Adjustable 1 – 8)
This option controls the number of retries a user will get when a prize arm times
out during the prize selection stage.
 P29 = WIN & BEACON LIGHT IN ATTRACT MODE
(Default ON) (Adjustable ON or OFF)
This adjustment turns the Win and Beacon lights in attract mode ON or OFF. This
adjustment helps prevent player and operator confusion when the Win and Beacon
Lights are activated during an attract mode.
* NOTE! *
 If all Prize Arms are set to [OFF] the error message [Err6] will be displayed
in the credit display. See Error Codes on page 29
1
2
4
5
6
8
PRIZE ARM NUMBER &
DEFAULT LOCATION
* NOTE! *
 Disabled Prize Arms are unable to be selected by Wining Players
* NOTE! *
If the machine fails to detect a prize fall after set number of re-tries
the error message [Err4] will be displayed in the credit display.
See Error Codes on page 29 for more detail.
