LAI Games Stacker Giant User Manual

Operator's Manual – Stacker Giant – SKILL
© LAI GAMES
Page 17
RUN TEST
 ENTER The Run Test can be entered by pressing the Test button once while in
the Switch Test or by pressing the Test button three times while in
Attract mode,
r
r
r
r
will be displayed on the 4-digit display.
 SELECT The Service button is pressed once to start the run test mode. The
credit display will indicate
r
-
0
1
, the first Major Prize Arm, and
also flashing the indicator LED. The Service button is then pressed
again to step through each prize arm, flashing the indicator LED of the
current prize arm. The last run test,
r
-
1
1
, is the capsule dispenser
motor test.
 RUN The Start/Stop Button will activate motor of the current selected prize
arm or capsule dispenser motor as long as the button is held.
 EXIT The Run Test is exited into Programmable Adjustments Mode by
pressing the Test Button once.
CODE DISPLAY FUNCTION
R01
r
-
0
1
Prize arm 1 selected
R02
r
-
0
2
Prize arm 2 selected
R03
r
-
0
3
Prize arm 3 selected
R04
r
-
0
4
Prize arm 4 selected
R05
r
-
0
5
Prize arm 5 selected
R06
r
-
0
6
Prize arm 6 selected
R07
r
-
0
7
Prize arm 7 selected
R08
r
-
0
8
Prize arm 8 selected
R09
r
-
0
9
Prize arm 9 selected
R10
r
-
1
0
Prize arm 10 selected
R11
r
-
1
1
Capsule Dispenser selected
PRIZE ARM LOCATION DIAGRAM
3 45
8
9
10
12 67
