Operator's Manual – Stacker Giant – SKILL
© LAI GAMES
Page 38
 Err5 – PRIZE SENSOR BLOCKED or PRIZE SENSOR FAULTY
This error usually occurs if the prize sensor is blocked or a prize is jammed
in the prize chute, blocking the infrared beam of the prize sensor for longer
then 5 seconds. This error can also occur if the sensor output pulses or
“flickers” due to miss alignment for more then 20 times every 5 seconds.
The sensor can be tested using the switch test, (See Page 16 for Details). If
the sensor is blocked C7 will be displayed in this test. Clear what ever is
blocking the sensor and the error will clear itself.
If you cannot find anything blocking the sensor, there could be faulty
infrared sensors or receivers on the prize sensor. The sensor PCB’s should
be returned to your nearest LAI Games distributor for repair.
The Prize Sensor is designed around 12 pairs of infrared detectors and
LEDs. Blocking the infrared path of any one of the 12 beams will trigger a
common output. There are 6 orange LEDs on each Sensor PCB to help
indicate the active pairs of infrared beams.
 Err6 – All PRIZE ARMS STATUS are DISABLED.
This error will only be displayed if programmable adjustments P14 to P23
(Major Prize Arm Status) are all set to OFF (Disabled).
There should be at least one Major Prize Arm Status set to ON. Push the
test button once to enter directly to P14 or P23 in adjustment mode, locate
what prize arms need to be active and set that Prize Arm Status to ON,
(See Page 18 for Details).
 Err7 – MINOR PRIZE DEPLOYMENT ERROR
This error is usually displayed if no capsules are dispensed after a Minor
prize-winner selects a minor prize.
Test the capsule dispenser using Run Test, (See Page 17 for Details). Use
the Switch Test and test the notch pulse by manually activating the micro-
switch on the ticket/capsule dispenser, an active notch will be display as
C1, (See Page 16 for Details). Also check that the dispenser setting for
minor prize is correct for the dispenser fitted (See page 22 for P28 setting).
If the game was out of tickets/capsules, replace the tickets/capsules, clear
the jam and then push the test button once to clear the error.
 Err8– PRIZE BOX GATE ERROR.
This error can occur if one of the prize box gates is open for more than 5
minutes. Check that there is no jam in the prize box gates and the sensors
are working properly.
* NOTE! *
P25 setting will affect what the action the game will take on an error 7 [Err7].
Please see Program Adjustments on page 17 for more information.
