POWER CORD
The power cord is a standard IEC power cord (as used on computers) that is
plugged in to the power inlet socket at the rear of the machine. The power cord
can be removed for transport.
POWER INLET
The power inlet is located at the rear of the machine on the Left-hand side as
viewed from the rear. It is a standard IEC inlet socket.
MAINS SWITCH
The mains switch is located on the power inlet assembly along with the mains
fuse, and IEC inlet socket.
FUSES
For locations of all fuses refer to Fuses and Fuse location, page 34 of this manual.
7-SEG DISPLAY
There is a 4-digit display located on the control panel. Access is through the back
of the machine.
PCB’s
For location of all game PCB’s, refer to the Parts Location diagram page 36 of this
manual.
POWER SUPPLY
The power supply is located at the back of the cabinet and is accessed from the
rear of the machine. It is a 12V 13A switching power supply.
DOWN LIGHT TRANSFORMER
The down light transformer is located at the back of the cabinet and is accessed
from the rear of the machine. It is 2 x 12VAC 5A supply output.
TILT SWITCH
The tilt switch is located to the left at the back of the cabinet and is accessed from
the rear of the machine.
MAJOR & MINOR PRIZE ARMS
The prize arm mechanisms are located at the back of the cabinet and are accessed
from the rear of the machine.
* WARNING! *
Always
turn OFF Mains power and unplugged the game, before replacing any
fuses
Always
use the correct rated fuse. Refer to page 34 for fuse information.
