VAPOURS SUCTION
For machines equipped with splashguard
with collar or normal collar, carry out the
necessary connection as showed in fig. 4.
In any case it is necessary to provide a
way to scavenge steam through a hood
or a similar system.
TESTING
Before starting machine:
During the testing operations, prior to
switching the dishwashing machine on,
check that thermostat of the rinsing boiler
(0°-90° C) is set to zero
and the direction of
rotation of the pumps is correct.
Should the pumps rotate in the reverse
direction, reverse two wires of the line .
Make a number of empty racks to pass
through, then check that water jets are
sprinkled fron the rinsing nozzles then
adjust the thermostat of the boiler to 85° C.
WORKING TEMPERATURES
Check that the thermostats are set
according to the following working
temperatures.
WASHING
The tank thermostat (CT3), also placed
near the wash tank, will be set according
to the following temperature:
Washing water: 55÷60°C.
RINSING
The rinsing thermostat (CT2) will be set
according to the following temperature:
Rinsing water: 80÷85°C.
DO NOT TAMPER WITH THE
THERMOSTAT CALIBRATION
