POSITIONING
During installation, carry out a good levelling
of the machine in order to make it correctly
work (doors, basket forward feeding).
In order to do so use the adjustable feet.
After removing front panels, position the
machine over the connections. Assemble the
inlet and outlet shelves for basket loading and
unloading. The limit switch FC1 is located on
the outlet shelf or on the machine delivery if
the shelf is not provided for. The limit switch
shall be connected to the outlet shelf.
The machine shall also be equipped with
detergent and brightener dispenser, which
shall be supplied by the manufacturer of these
products.
ELECTRICAL CONNECTION
Before connecting the machine,
check to make sure the voltage
outlet of the mains is the same as
the voltage specified on the data
plate of the machine.
It is also necessary to check that the
counter, the mains and the intake are
adequately dimensioned to withstand the
required maximum load.
A main switch must be installed between
the mains and the machine. This safety
measure also requires that the minimum
distance between the switch contacts is at
least 3 mm and the disconnection on all
poles according to EN 60204 (VDE 113).
The mains must be wired to be able to
handle the current drawn by the
machine.The system must also be
provided with a proper ground lead in
accordance with the existings norms. The
electric cable must be of the following
type H07RN-F.
For a correct selection of the cable rated
cross-section refer to the data reported on
the product data plate.
The cable cross-section shall not be
inferior to the one indicated in the
“Technical data and description” reported
in the first page of the present manual.
The cable shall be connected to the
terminal L1-L2-L3 and to the adjacent
yellow-green terminal,on the electric box,
it shall be made passed and stopped by
means of the apposite cable grip.
It is necessary to connect the equipment
to an effective ground installation, as
specified by the electrical safety
regulations in force.
Chack that this basic requirement is
complied with and, in case of doubt, ask
for a careful check of the installation by a
qualified personal.
In addition, the equipment shall be part of
an equipotential system, the effectiveness
of which should be checked according to
the regulations in force.
The connection should be made at the
screw marked by the respective label
located on the equipment lower side (
).
It is recommended to make the electric
line be checked by your own designer.
THE MACHINE SHALL BE
CONNECTED WITH AN EFFECTIVE
GROUND CLAMP.
The manufacturer declines any
responsibility for any damages
caused by lack of an effective
ground installation.
