48
8.9 - WASHING FLOW CONTROL SYSTEM
pos. “1”
pos. “2”
Highest power (position 1) Lowest power (position 2)
The flow control system is a device that allows You to act on the intensity of the washing
power.
This can be useful by washing glasses, when it is necessary to reduce the washing jet
power.
This device is placed into the pre-washing and washing areas of the rack conveyor
dishwashing machines, by the lower washing arms group.
Warning! Before working on this device, make sure that the inside of the machine has
reached ideal temperatures for any individuals having to intervene.
Warning: do not open the door too quickly. Any hot water jets may be dangerous!
In order to act on the control system You have to rotate the lever “A” by hand anticlockwise
to rise the washing jet power and clockwise to reduce it.
If You turn it thoroughly leftwards, You get the highest power (pos.1).
If You turn it thoroughly rightwards, You get the lowest power (pos.2).
