Lamona LAM8607 - Items Not Suitable for Dishwasher; Cutlery Basket and Height Adjustment

11
Exclusive to Howdens
(4x13) x2
Stage 8 screws x2
A
(4x13) x2
Stage 8 screws x2
A
=
=
TOP
Centre line
267mm
517mm
267mm
267mm
60mm
130mm
130mm
=
267mm
2 x 356mm drawer fronts = 712mm
Normal door height = 716mm
Therefore space between
drawer fronts = 3-4mm
TOP
Centre Line
=
517mm
267mm
267mm
9 - Standard decor door preparation
10 - Decor drawer frontals preparation
Remove centre rail.
