www.howdens.com
DO NOT use high speed
impact power tools.
DO NOT damage the
plastic screw heads.
+
Flat head
screw driver
_
+
_
Plus foot
addition
+50mm
Foot,
max
50mm
10-15mm
x2 x2
For standard installation,
extension feet need to
be fitted.
3 - Fit feet and raise to 10-15mm below worktop height
Front feet
Rear feet
4 - Profile kitchen
Do not position
in cabinet run at
this stage.
Pre-install an infill when fitting a dishwasher into a Profile Kitchen.
It is critical that
the dishwasher is
installed level.
RKC0071 x2
Apply moisture barrier tape.
