168
7 Operating Control and Displays
Fig. 7-38 Offline mode
7.3.2.2 Online Mode
In ONLINE mode the end device is synchronised. The data of the end device are read out
completely. The permanent connection to the end device is monitored from both sides with a
time-out. While establishing connection to the device all functions are locked.
7.3.2.3 Connecting the CMS to the PC
Access code/access levels
See chapter 7.3.3.3 Access Rights Menu
Access code/access levels
See chapter 7.3.3.3 Access Rights Menu
Establishing a connection between PC and CMS
1. Establishing a connection between PC and MCC
Fig. 7-39 Connecting PC to MCC via Ethernet
NOTICE
The IP addresses must not be the same.
The IP addresses must be in the same subnet.
2. Open the CMS remote software
