182
7 Operating Control and Displays
Parameter
Accessing the ’All parameters’ submenu
Fig. 7-58 CMS all parameters window
Setting and changing values
1. Double-click to select the parameter value.
Alternative: use arrow keys to select up/down and then confirm with the ENTER key
2. Change the value by clicking the or buttons or by using the up/down arrow keys on
the keyboard.
3. Confirm value with the ENTER key or select a different parameter.
NOTICE
Only parameters at the current access level can be changed!
All parameters not at the current access level are greyed-out and cannot be changed.
A reset must be performed after changing some parameters. This is indicated with a system
message.
1 Enter the password (padlock symbol) 2 A search using groups is possible
