Landa PG4-3500 - Unloader Exploded View and Parts List

LANDA PG 8.913-910.0
OPERATOR’S MANUAL
PRESSURE WASHER
30
REPAIR KIT
NUMBER
8.916-488.0 8.916-487.0 8.916-322.0 8.916-323.0 9.802-607.0 9.802-611.0 9.802-603.0 9.802-606.0
KIT DE-
SCRIPTION
Plunger
"U" Seal
20mm
LT-4040.1,
LT-6035.1
LT-4035.1
Plunger
"U" Seal
22mm
LT-5030.1
"U" Seal
Packing Assy
20mm
LT-4040.1
LT-6035.1
LT-4035.1
"U" Seal
Packing
Assy
22mm
LT-5030.1
Plunger
20mm
LT-4040.1
LT-6035.1
LT-4035.1
Plunger
22mm
LT-5030.1
Complete
Valve
(all pumps)
Plunger Oil
Seals
(all pumps)
ITEM NUM-
BERS
INCLUDED
4, 7, 22 4, 7, 22
4, 5, 6, 7, 8,
20, 21, 22,
23
4, 5, 6, 7,
8, 20, 21,
22, 23
35, 36, 37,
38, 39, 40
35, 36, 37,
38, 39, 40
12, 13, 14 3
LT PUMP EXPLODED VIEW PARTS LIST (CONT)
ITEM PART NO. DESCRIPTION QTY
39* 9.803-187.0 O-Ring Ø1.78 x10.82 3
40* 9.803-154.0 Teflon Ring 3
41* See Kit Below Plunger 3
42* See Kit Below Copper Spacer 3
43 9.803-143.0 Plunger Rod 3
44 9.803-157.0 Connecting Rod 3
45 9.802-912.0 Snap Ring 6
46 9.802-915.0 Connecting Rod Pin 3
47 9.802-889.0 Spring Washer 6
48 9.802-937.0 Connecting Rod Screw 6
49 9.803-194.0 O-Ring Ø2.62 x 152.07 1
50 9.803-166.0 Crankcase Cover 1
51 9.803-197.0 Gasket, G3/8 1
52 9.803-202.0 Sight Glass G3/4 1
53 9.802-939.0 Cover Screw 5
* Part available in kit (See below)
