ASSEMBLING YOUR L&L EASY-FIRE KILN
easy-fire-install.pdf 3/1/2007 Rev 1.3 Page 5
2007 L&L Kiln Mfg, Inc. 505 Sharptown Rd, Swedesboro NJ 08085 P:856.294.0077 F:856.294.0070 sales@hotkilns.com hotkilns.com
3) Attach the flexible vent tube to the outlet of the
vent collection box. This takes some patience to get
the flexible tube around the fitting.
Installing the flexible duct onto the Bypass
Collection Box of the Vent-Sure Vent System:
4) Fit the rubber-plastic feet over the bottom of the
legs. The stand is now fully assembled.
The fully assembled stand:
REMOVING THE LID
The next step is to remove the lid from the kiln.
Remove the cotter pin, then the hinge pin, pull the bar
out and remove the spring. Set them aside. Remove
the lid from the kiln.
The hinge is shipped assembled (without the
spring engaged). This way you can see how it all
goes back together.
Now you can remove the top :
