Landmann 31342 - Delivery Specifications

4
LANDMANN
Delivery specications
Pos. Number Designation
1 2 Wheel leg
2 1 Cart base
3 2 Elbow
4 1 U-section
5 1 Standing leg
6 1
Panel with LANDMANN logo
7 2 Wheel
8 2 Wheel cap
9 1 Fire bowl
10 1 Flue with adjustable ventilation
11 1 Cutlery holder
12 1 OptiHeat cooking grill support
13 1 Lid handle with integra-
ted heat protection
14 1 Lid with adjustable ventilation
15 1 Thermometer set (with mount)
16 1 Ash collecting pot
17 1 Charcoal grid
18 1 OptiHeat cooking grill
19 2 Coal divider (for indirect grilling)
Connecting elements:
s1 6 M6 x 35 mm bolt
s2 7 M5 x 10 mm bolt
s3 2 M6 x 15 mm bolt
s4 2 M5 x 35 mm bolt
n1 6 M6 nut
n2 2 M8 nut (self-locking)
n3 4 M5 nut
w1 2 Ø 9/16 mm washer
w2 7 Ø 6.5/20 mm washer
w3 2 Ø 9/20 mm washer
2
3
11
12
9
13
14
15
16
8
7
7
8
1
1
10
5
6
3
4
s1
n1
n2
17
18
19
19
s2
n3
w2
w1
s4
s3
w3
