LW 225 E / LW 245 B
Version: 19.11.2015
M A I N T E N A N C E A N D S E R V I C E
Motor change
The drive motors of the LW 225 and LW 245 are generally interchangeable.
Motor change as follows:
• Switch off the compressor unit, pull the plug if necessary
• Remove V-belt cover
• Remove mounting screws of the motor flange
• Remove motor tensioner bolt
• Remove V-belt
• Remove motor v-belt pulley
• Remove motor carefully
• Place new motor
• Mount motor v-belt pulley
• Mount flange mounting screws and tighten nuts slightly
• Insert motor tensioner bolt
• Check/Ensure the alignment of both key slots (motor & compressor)
• Tension V-belt
• Tighten flange mounting screws
• Place V-belt cover and tighten mounting screws
• Ensure clearance of the V-belt cover
Warning
Do not carry out modifications when the unit is hot.
!
