55
TECHNICAL DATA
TRANSFORMER RESISTANCE
TRANSFORMER Input Primary Secondary Output
120/24 Volt 120 Volt
18.9 1
24 Volt
120/12 Volt 120 Volt
154.1 1
12 Volt
24/24 Volt 24 Volt
2.7 3.4
24 Volt
CONTACTOR RESISTANCE
CONTACTOR Coil
3 Pole 24 Volt coil
6
2 Pole 24 Volt coil (P & B) (PP & PT motor)
35
RELAY RESISTANCE
RELAY Coil
24 VAC
82
OVER-TEMP THERMOSTAT
OVER-TEMP
Wires Normally closed
DOOR SWITCH
Check switch between “COM” (common) and “NO” (normally open) contacts, insure switch closes approximately 3 to 4
inches before door closes.
BLOWER FAN
Blower fan will rotate clockwise and should have a 5/8“ gap between it and the back wall of the can.
AUTO/BYPASS SWITCH
The Auto / Bypass and Energy switch are located below the controls behind a pull down access panel
Auto/Bypass switch Normally in “OFF”
. The “ON” position will interrupt
power to the computer and allow use of the back-up
thermostat.
Energy switch Normally in “HIGH”
for 11 kW heats. “LOW” WILL
PROVIDE 8.25 kW heat. Not provided on Steam
convection ovens.
