Lanner NCA-1516 - Installing M.2 Module for Storage; Locate M2_1 Slot for Storage; Align and Insert M.2 Storage Module; Secure M.2 Storage Module

NCA-1516 User Manual
22
The motherboard supports one M.2 storage on M2_1. Follow the instructions below for installation.
1. Locate the M2_1 slot.
2. Align the notches of the module with
the socket keys in the slot, and insert
it at 30 degrees into the socket until it
is fully seated in the connector.
3. Push down the module and secure it
with the screw that comes with it.
2
3
Socket
Key
Socket
Key
1
