Lanner NCA-1516 - Rack-mounting the System; Rack-mount Kit Components; Attaching Ear Brackets to Chassis

NCA-1516 User Manual
35
With the rack mount kit, this system can be fixed onto rack posts. Please contact Lanner‘s sales representative
for purchasing this kit.
Check the kit for the following items:
2x Ear Bracket
1x Adapter Bracket
1x Adapter Holder
Screws for the fixture of the Brackets and the
Holder (8x Screw A, 2x Screw B)
1. On one side of the system, align the ear
bracket to the screw holes on the side
panel and fix it using 3 screws (Screw A).
2. Secure the other ear bracket to the other
side of the system.
Ear Bracket
Adapter Bracket
Screw A
Screw B
Adapter holder
