Lanner NCA-1516 - Rack-mount Adapter Installation; Adapter Holder Assembly Procedure; Attach Adapter Holder to System; Secure Adapter Cable to Holder

NCA-1516 User Manual
36
3. The adapter holder assembly is designed to secure a 5V adapter or a 3V adapter. Secure the adapter
onto the holder with the adapter bracket and 2 provided screws (Screw B). Make sure the way you place
the bracket is as shown in the picture.
4. Attach the adapter holder to the left side of system and secure it with 2 screws (Screw A)
5. Secure the adapter’s cable onto the adapter holder.
Adapter
Adapter Bracket
