8
CONTACT
For questions and technical support, please check our online knowledge base
at www.lantronix.com/support
Lantronix
15353 Barranca Parkway, Irvine, CA 92618, USA
Phone: (949) 453-3990 or Fax: (949) 453-3995
www.lantronix.com
W W W . L A N T R O N I X . C O M
13
Q u i c k S t a r t G u i d e
E D S 8 / 1 6 P S
LEDS
MEANING
Transmit (green) Blinking = EDS is transmitting data on the serial port.
Receive (yellow) Blinking = EDS is receiving data on the serial port.
Power (blue) ON = EDS is receiving power.
Diagnostic (yellow) Fast blink = initial startup (loading OS).
Slow blink (once per second) = operating system startup.
ON = unit has finished booting.
Speed (yellow) ON = EDS is connected to a 100 Mbps Fast
Ethernet network.
OFF = EDS is connected to a 10 Mbps Ethernet network.
Activity (green) Blink = EDS is sending data to or receiving data from the
Ethernet network.
