Lantronix UDS2100 Quick Start Guide

8
WWW.LANTRONIX.COM
9
Quick Start Guide
UDS2100
CONFIGURE THE UDS2100
Once the UDS2100 is in the device list, it can be configured.
1. Double-click the unit in the list. Details about the unit display.
2. Select one of the following tabs:
Note: For details about configuration settings, see the UDS2100 User Guide.
LED TROUBLESHOOTING
The following LEDs are on the top of the UDS2100:
 Power / Diagnostic (Blue)
 RX Serial 1 Activity LED (Green)
 TX Serial 1 Activity LED (Yellow)
 RX Serial 2 Activity LED (Green)
 TX Serial 2 Activity LED (Yellow)
The following LEDs are on the RJ45 Ethernet connector:
 Ethernet Link LED on the left (Bi-color, 10Mbps = Yellow,
100 Mbps = Green)
 Ethernet Activities LED on the right (Bi-color, Half Duplex = Yellow,
Full Duplex = Green)
LEDS MEANING
Power/Diagnostic (Blue) Steady On = Power OK
Blinking 2x = No DHCP response
Blinking 2x = Setup Menu active
RX Serial 1 Activity LED (Green) Off = No data activity
Blinking = Data being received by UDS2100 on channel 1
TX Serial 1 Activity LED (Yellow) Off = No data activity
Blinking = Data being transmitted from UDS2100 on channel 1
RX Serial 2 Activity LED (Green) Off = No data activity
Blinking = Data being received by UDS2100 on channel 2
TX Serial 2 Activity LED (Yellow) Off = No data activity
Blinking = Data being transmitted from UDS2100 on channel 2
Ethernet Link LED Off = No Ethernet link established
on the left (Bi-color) Solid Yellow = 10Mbps Ethernet link established
Solid Green = 100 Mbps Ethernet Link established
Ethernet Activity LED Off = No data activity
on the right (Bi-color) Blinking Yellow = Half Duplex data activity
Blinking Green = Full Duplex data activity
CONTACT
For questions and technical support, please check our online knowledge base
at www.lantronix.com/support
Lantronix
15353 Barranca Parkway, Irvine, CA 92618, USA
Phone: (949) 453-3990 or Fax: (949) 453-3995
www.lantronix.com

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
