2
LARIUS 2 - painting
English
A
B
WORKING PRINCIPLE
The LARIUS 2 unit is defined as being a “diaphragm pump” that
is used for low pressure painting. This type of equipment can be
used to paint using a number of spray guns.
The feed passes through a low pressure flow regulator, fitted with
a pressure gauge.
LARIUS 2
MAX WORKING PRESSURE (product)
MAX (air) SUPPLY PRESSURE
AIR INLET PRESSURE
PUMP AIR CONSUMPTION
WEIGHT
LEVEL OF THE SOUND PRESSURE
LENGTH
WIDTH
HEIGHT
7 bar
7 bar
7 bar
120 L/min
22 Kg
≤ 70dB(A)
(A) 500 mm
(B) 600 mm
(C) 1060 mm
The LARIUS 2 can also be used as a transfer pump.
TECHNICAL DATA
RATIO 1:1
C
A
B
