30
WARNING!
Personal injury or material damage possible
due to loss of the bike carrier during the
journey.
Riding with a bike carrier which is extended can
result in detachment of the carrier or the coupling.
Slide the carrier forwards before the start of the
journey (see g. 5 of this chapter).
4
The sliding mechanism locks back (you hear
two clicks) by sliding back the entire bicycle
carrier. Both levers are in the low position (see
gure 6).
4
Check that the bike carrier is properly secured
in this position.
4
5
6
Dismantling the bike carrier
To dismantle the bike carrier, proceed in the reverse order to tting:
Unlock the U-tube and rearlights and fold it down into the
storage position.
4
Fold the bike carrier together.
4
Remove lighting connector from the car.
4
1
2
3
The ingenious folding system makes it convenient to carry and to
store.
Release the quick-connector lever and pull the bike carrier of the
towball.
4
