LaserLine 996 kit - DIAGRAM 1; Alarm System Wiring Overview

ENGLISH
19
DIAGRAM 1
ELECTRONIC KEY
WHITE
RED
GROUND
J18
J17
J24
RED(siren)
BATTERY
IGNITION SWITCH
DIRECTION
LIGHT
DOOR/BOOT
CONTACT
WINDOWS CLOSERS
MODULE
art. 811,824,828
POSITIVE OUTPUT
DURING THE ALARM
(MAX. 3A)
ENGINE
IMMOBILISATION
SIREN CONNECTION
CENTRAL DOOR
LOCKING
ULTRASONIC
SENSOR
WHITE
BROWN
LIGHT BLUE
YELLOW
J4
ULTRASONIC ADJUSTMENT
R T
J2
J1
J3
J7
J8
J9
BLACK
WHITE
ORANGE
BROWN
GREY
RED
GREEN-BLACK
GREY-BLACK
LIGHT BLUE-BLACK
YELLOW-BLACK
RED-BLACK
BROWN-BLACK
!
DO NOT LEAVE
LIGHT BLUE WIRE
DISCONNECTED
SEE DIP SWITCH
CODING TABLE
SEE DIAGRAM 3
R
T
SEE DIAGRAM 4
SEE DIAGRAM 2
BLACK(siren)
YELLOW
AERIAL
+12V
