ENGLISH
21
DIAGRAM "3/A"
FOR VEHICLES WITH MULTI POINT CENTRALISED
DOOR LOCKS (NEGATIVE POLE TYPE)
GREEN/BLACK- YELLOW/BLACK: connect to ground
GREY/BLACK: negative impulse for closing
BROWN/BLACK: negative impulse for opening
LIGHT BLUE/BLACK - RED/BLACK: not used
DIAGRAM "3/B"
FOR VEHICLES WITH MULTI POINT CENTRALISED DOOR
LOCKS (POSITIVE POLE TYPE)
GREEN/BLACK - YELLOW/BLACK: connect to a fused positive supply
GREY/BLACK: positive impulse for closing
BROWN/BLACK: positive impulse for opening
LIGHT BLUE/BLACK - RED/BLACK: not used
DIAGRAM "3/C"
FOR VEHICLES WITH SINGLE POINT CENTRALISED DOOR LOCKS
(CONTROL ONLY FROM ONE POSITION)
LIGHT BLUE/BLACK - RED/BLACK: connect to ground
GREEN/BLACK - YELLOW/BLACK: connect to a fused positive supply
GREY/BLACK: connect to the blue wire of the central locking motor
BROWN/BLACK: connect to the red wire of the central locking motor
DIAGRAM "3/D"
FOR VEHICLES WITH MULTIPOINT VACUUM CONTROLLED CENTRAL LOCKING
GREEN/BLACK: connect to the ground
YELLOW/BLACK: connect to a fused positive supply
GREY/BLACK - RED/BLACK: connect to each other
Locate the wire coming from the driver's or passenger's side front door which controls the CDL
pump operation. Cut it and connect the wire coming from the pump to the BROWN/BLACK
wire. Connect the wire coming from the door to the LIGHT BLUE/BLACK wire.
CENTRAL DOOR LOCKING CONNECTION
Via Don Locatelli 51 20040 RONCELLO (Milano) Italy
Tel. 039/6820009 - Fax 039/6820031 - P. IVA 00838610962
INTERNET http://www.laserline.it
E-mail laserline@galactica.it
Is996v2 ita-ing.pm6 05/03/98, 16.2721
