MoistureMaster Compact Plus
23
EN
In addition to numeric measurement display in % of relative material moisture,
the LED display also provides a material-dependent evaluation of moisture.
The LED display bar becomes larger, from left to right, with increasing moisture
content. The 12-position LED display is subdivided into 4 green (dry), 3 yellow
(moist) and 5 red (wet) segments. Wet material causes an additional acoustic
signal.
Wet/dry LED indicator
13
Green = dry Yellow = moist
Red = wet
The classification "dry" means that materials in a heated room have
reached a balanced moisture level and are thus suitable for further
processing.
!
Application notices
14
Place the device such that the sensor
pads fully rest on the material to be
measured and exert a pressure of
about 2.5 kg onto the surface to be
measured.
TIP: Use scales to test the contact
pressure.
Always hold and press down the
measuring device in the same way
(see illustration).
