LaserPecker LX1 - Technical Specifications

07
Material
File Format
Connection Mode
Operating Systems
Power Input
Working Temprature
Working Humidity
LX1 Unfolded: 578mm*558mm*196mm LX1 Frame Folded: 578mm*94.8mm*196mm
LX1 Frame with Protection Cover: 647mm*632mm*315mm
LX1 Max Unfolded: 578mm*558mm*196mm LX1 Max Frame Folded: 578mm*94.8mm*196mm
LX1 Max Frame with Protection Cover: 647mm*632mm*315mm
Anodized Aluminum Alloy
Support iOS 9.0 +, Android 6.0 +, MacOS 10+, Windows 10+
APP & Software
LaserPecker Design Space(PC&APP)，LightBurn
DC（24V 5A)
AC (100-240V 50-60HZ）
Temprature: 0℃~50℃
Humidity: 5%~80%
Whole Unit Weight
Module Weight
Working Area
Size
Product Name
Certification Project
Laser Class under
LP Protection Cover
Bluetooth Connection; USB Connection (2375-2525MHz)
APP: G-code/JPG/PNG/BMP;
Software: SVG/DWG/DXF��
CE,ROHS,WEEE project，UL project，CA65，PSE，UKCA，GB4943，FCC，
IC-ID，NCC，KCC，SRRC，TELEC
2.9 Specifications
Class 1
LaserPecker LX1& LX1 Max
LX1:5kg LX1 Max:5.76kg
Laser Spot
(Diameter)
Laser
Module
Cutting Depth
548g 436g702g618g
10W
0.08mm 0.08mm 0.03mm 0.3-5mm
20W 2W
Laser Output Power
450nm(Blue Laser)
8mm Plywood
8mm Arcrylic
15mm Plywood
10mm Arcrylic
450nm(Blue Laser) 1064(Infared Laser)
\
\
\\
Four Modules Settings
10w 450nm Module 20w 450nm Module 2w 1064 nm Module Artist Module
LX1:400*420mm LX1 MAX:400*800mm
LX1 Artist Module:400*400mm LX1 MAX Artist Module:400*780mm
