Setting up a grade / slope
▪ To create a slope / grade, enter into
manual mode by pressing the manual
/ automatic mode button on either the
instrument or remote control.
▪ The manual / automatic mode indicator
on the instrument will light up when manual
mode is active.
▪ To adjust the grade, press the grade
adjustment arrows on either the instrument
or remote control. These arrows will adjust
the grade on either the x-axis or y-axis.
▪ To cancel out of manual mode press the
manual / automatic mode button.
When in manual mode the instrument
will not self level and correct for
vibrations and/or disturbances.
i
Power supply
▪ The remote is powered by two AAA
alkaline battery.
Battery replacement
▪ Remove the battery door cover.
▪ Insert the battery according to polarity and
replace the battery door.
Remote operation
▪ Ensure the instrument is turned on and the
laser head is rotating.
▪ To create a grade / slope press the grade
adjustment arrows.
USING YOUR REMOTE
OPERATION (continued)
