EMC
This tester was designed in accordance with
EMC Standards in force and its compatibility
has been tested in accordance with
EN61326-1 (2006).
9.2 Electrical Specifications
Unless otherwise stated, the following
specifications hold under the following
conditions:
The meter is located in the far field of a
source; the sensor head is pointed towards
the source.
Ambient temperature : +23 °C ±3°C.
Relative air humidity 25%~75%
Sensor type : electrical field (E).
Frequency range : 10MHz ~ 8 GHz.
Specified measurement range:
CW signal (f >50MHz) : 38mV/m to 11.00
V/m, 53.0uA/m to 28.64mA/m 0.1uw/m
2
to
309.3mW/m
2
, 0uW/cm
2
to 30.93mW/cm
2
Dynamic range : Typically 75dB
Absolute error at 1V/m and 2.45GHz:
± 1.0 dB.
