RF Explorer User Manual page 46
The Power Limiter is assembled in a rugged aluminum case and it is very compact when compared to other
market offerings, not to mention it includes internal DC block and attenuator which makes it a really small
device for what it offers. It is a recommended add-on to all users who may expose their unit to strong
external fields.
For more details and ordering visit this link.
Feature
• Robust, small and low weight custom aluminum case
• 3-in-1 device with Power Limiter, DC Block and Attenuator
• Easy to connect and disconnect when required
• Wide broadband frequency application
• Directional 1 Watt rating
• Suitable for all RF Explorer models, not required for WSUB3G.
Specification
• Frequency range: DC ~ 3.0 GHz
• DC block: +16V DC
• Input Power rating: 1 Watt (+30dBm)
• Output power max: +4 dBm
• Attenuation: 6 dB
• Impedance (Nominal): 50Ω
• V.S.W.R (Max): 1.25 : 1
• Connector type: SMA male – female
• Connector: Brass / Gold plating
