INVERTER CONFIGURATION
Dip Switch Settings
In order to access these options you have to open the inverter. Before altering the settings
switch inverter OFF, adjust the setting and switch inverter back ON again. We recommend these
adjustments be carried out by a suitably qualied electrical worker.
SW1 50/60 Hz
ON = 50Hz (factory setting) OFF =60Hz
If you need to operate American or Japanese equipment this option will allow your inverter to
operate at 60Hz. Please note you may also need to change the output voltage to suit equipment.
SW2/SW3 Output Voltage
SW2 OFF & SW3 OFF = 240V a.c. (factory setting)
SW2 OFF & SW3 ON = 230V a.c.
SW2 ON & SW3 OFF = 225V a.c.
SW2 ON & SW3 ON = 220V a.c.
These two switches regulate the output voltage, please keep in mind these values are ±4%
SW4 Automatic Reset
OFF=Disabled ON=Enabled (factory setting)
This feature is designed to restart the inverter and maintain power in the event of an external
fault. Should the inverter shut down due to under voltage, over temperature or any fault
condition it will attempt to reset every 8 minutes until the fault condition clears and normal
operation resumes.
For over load shutdown the inverter will only attempt 5 restarts. If the inverter can not resume
normal operation within 5 restarts, it will remain OFF until reset manually. This prevents
continuous re-application of power to faulty appliances or wiring.
SW5 & SW6 Under Voltage Settings
SW5 OFF & SW6 OFF= (Factory setting)
For under voltage shutdown the inverter will restart when the battery voltage reaches the
reconnect value as shown in the table below.
SETTING 12V VALUE 24V VALUE 48V VALUE
SW5 SW6
DISCONNECT RECONNECT DISCONNECT RECONNECT DISCONNECT RECONNECT
ON ON 10.0 12.0 20 24 40 48
OFF OFF 10.5 12.5 21 25 42 50
ON OFF 11 13.0 22 26 44 52
OFF ON 11.5 13.5 23 27 46 54
13
