Specication Table
INVERTER MODEL
LS-2012 LS-2324 LS-2548 LS-3024 LS-3548 LS-4024 LS-5048 LS-7048
Nominal D.C. Voltage 12V 24V 48V 24V 48V 24V 48V 48V
Continuous Power 2000W 2300W 2500W 3000W 3500W 4000W 5000W 7000W
1/2 Hour Rating 2200W 2800W 3000W 3700W 4100W 4500W 6000W 8500W
Surge Rating (5 Secs) 6000W 7000W 7500W 9000W 10500W 12000W 15000W 20000W
Input Voltage Range 10.5-17V 21-34V 42-68V 21-34V 42-68V 21-34V 42-68V 42-68V
Standby Current 75mA 45mA 35mA 50mA 40mA 60mA 55mA 60mA
Inverter ON - No Load 1.10A 0.51A 0.30A 0.60A 0.33A 1.10A 0.47A 0.49A
Peak Eciency 90% 94% 94% 93% 94% 94% 95% 95%
Weight 22Kg 22kG 22Kg 24Kg 24Kg 30Kg 30Kg 34Kg
Dimensions 370mm(L) x 386mm(W) x 180mm(H) 475mm(L) x 458mm (W) x
187mm(H)
Output Voltage 240Vac +/- 4%
Output Frequency 50Hz +/- 0.1%
Output Waveform True Sinewave
THD < 4%
Power Factor All Conditions
Autostart Sensitivity 0-20 W Adjustable
Operating Temperature -20°C to + 40°C
D.C. to A.C. Isolation 3500V
Protection Circuitry Overtemperature, Overload/Short Circuit, Battery Undervoltage/Overvoltage
Battery Leads 1.5m Long with 10mm Mounting Lugs
A.C. Output Wiring 3 Terminal Hardwired Junction Box, Labeled ‘AC Output’
A.C. Input Wiring 3 Terminal Hardwired Junction Box, Labeled ‘AC Input’
A.C. Transfer Switch 240Vac, 40Amps, 50Hz (Surge 80a 0.5 Seconds) - Only with KX Option
Chassis (Powder coated) 3mm Aluminium 4mm Aluminium
Warranty 3 Years Parts and Labour (Back to Factory)
Standards IEC 62109-1, IEC 62109-2, AS3100, EN55014 & RCM
Ratings Specications @ 25°C Ambient Nominal Battery Voltage & Unity Power Factor
Operating Environment 5% - 95% (Non-Condensing) Humidity, up to 2000m About Sea Level
SPECIFICATIONS & SERIAL NUMBER
22
The below specication table is for a standard LS model inverter.
Any options added to the inverter which are indicated by letters after the standard model
number can change the below specication.
Due to constant improvements, specications are subject to change without prior notice
