Lattice Semiconductor HW-USBN-2B User Manual

Programming Cables
User Guide
© 2009-2019 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02042-26.2 7
To System
Board
To PC
6
1
Function
V
CC
SDO/TDO
SDI/TDI
ispEN/Enable/PROG
TRST/DONE
MODE/TMS
GND
SCLK/TCK
INIT
Color
Red
Brown
Orange
Yellow
Green
Purple
Black
White
Blue
HW-USB-1A
®
Figure 3.2. Programming Cable In-System Programming Interface for the PC (HW-USB-1A or HW-USB-2A)*
*Note: Lattice PAC-Designer
®
software does not support programming with USB cables. To program ispPAC devices with these cables,
use the Diamond Programmer/ispVM System software.
Function
V
CC
SDO/TDO
SDI/TDI
ispEN/Enable/Prog
TRST
MODE/TMS
GND
SCLK/TCK
To
System
Board
Color
Red
Brown
Orange
Yellow
Green
Purple
Black
White
6
1
25-pin
Parallel
Port
Adapter
HW7265-DL3 and HW7265-DL3A – Grey Housing with RJ-45 Connector
Other Cables are Labeled with Part Number
To PC
Figure 3.3. Programming Cable In-System Programming Interface for the PC (HW-DLN-3C and Equivalents)*
*Note: HW7265-DL3, HW7265-DL3A, HW-DL-3B, HW-DL-3C and HW-DLN-3C are functionally equivalent products.
6'
1
2
3
4
5
Function Pin #
6
7
8
.01f*
Capacitor
End View
Note: Capacitor Recommended on System Board
25-pin
Parallel
Port
Adapter
RJ-45 Connector
Eight Positions
pDS4102-DL2 – Blue Housing
pDS4102-DL2A – Grey Housing
.100" Center-Spacing
Eight Positions
V
CC
SDO/TDO
SDI/TDI
ispEN/Enable/PROG
TRST
MODE/TMS
GND
SCLK/TCK
To PC
To System
Board
Figure 3.4. Programming Cable In-System Programming Interface for the PC (pDS4102-DL2 or pDS4102- DL2A)
Figure 3.5. Programming Cable In-System Programming Interface for the PC (HW7265-DL2 or HW7265-DL2A)*
*Note: For reference purposes, the 2 x 10 connector on the HW7265-DL2 or HW7265-DL2A is equivalent to Tyco 102387-1. This will
interface to standard 100-mil spacing 2 x 5 headers, or a 2 x 5 keyed, recessed male connector such as the 3M N2510-5002RB.
