LAUDA Ultra-Thermostats
UB 20(-D), UB 25, UB 50, UB 30, UB 40
UB 20 F, UB 20 J, UB 30 J, UB 40 J, UB 65 J
UB 20 JL, UB 30 JL, UB 40 JL
YATE0013 / 10.04.02
- 59 -
IN_5 invalid
IN_6 invalid
IN_7 indication of the temperature of the external probe T
2
IN_8 indication of the current low temperature switch-off point T
U
IN_9 indication of the current overtemperature switch-off point T
O
IN_A indication of the current value of X
p
IN_B indication of the current value of T
n
IN_C indication of the current value of T
v
Examples:
A BASIC programme used to transfer values from the thermostat to the computer and to
display them specifying the channel number (e.g. 1 for IN_1, i.e. the bath temperature),
is as follows:
Note: set baud rate to 4800 (see Item 9.4.5)!
10 OPEN "COM1:4800,N,8,2" AS #1
20 CLS
30 LOCATE 8,5:PRINT SPC(20)
40 LOCATE 8,5
50 INPUT "Channel No.";NO$
60 PRINT #1;"IN_"+NO$
70 INPUT #1;A$
80 LOCATE 12,5:PRINT SPC(50)
90 LOCATE 12,5:PRINT "Response of the thermostat";A$
100 TI = TIMER+1
110 IF TI > TIMER THEN 110
120 GOTO 30
130 END
The isolation of the status data may be as follows:
LEFT $ (A$,1) = overtemperature fault
MID $ (A$,2,1) = low-level fault
MID $ (A$,3,1) = programme segment running
MID $ (A#,4,1) = control by T
i
, T
1
or T
2
MID $ (A$,5,1) = analogue input on/off
MID $ (A$,6,1) = external Pt 100 T
1
connected
RIGHT $ (A$,1) = external Pt 100 T
2
connected
