16 / 134 ECO Gold 09/2021
Control panel and display ECO GOLD
Display
Control panel
1 Expanded status display
5 Soft keys, left and right
2 Status display
6 Enter key
3 Display of the internal or external tempera-
ture value (T
int
or T
ext
)
7 Cursor keys (cursor keys) for Up, Down, Left
and Right.
4 Soft-key bar
8 Taste T
max
: Display and adjustment of the
over-temperature switch-off point
1
2
3
4
5
5
6
7
8
