LAUMAS W100 - Test; Date and Time Setting; Info Menu

- 28 -
TEST
- Input Test:
: ensure that for each open input  is displayed,  is displayed when the input is closed.
- Output Test:
: setting  ensure that the corresponding output opens. Setting  ensure that the
corresponding output closes.
- E/EC Option Test:
: It shows the group number of setpoint selected by the E/EC option, if the option is not
present or is not active, the message  is displayed.
- Analog Output Option Test:
: It allows the analog signal to range between the minimum and the maximum values
starting from the minimum.
: current output test.
: voltage output test.
- Millivolt Test:
: displays the load cell response signal in mV with four decimals.
DATE AND TIME SETTING
Selecting the  item in the main menu, access is obtained to the date and time display menu.
Pressing ENTER several times scrolls through days - months – years and hours – minutes; pressing
◄ selects the figure to modify; pressing ▲ the figure increases; pressing ENTER you can confirm
and go to the next menu item.
INFO MENU
: active options are displayed.

+
 


+
 


+
 

