Launch TLT235SB - Page 15

LAUNCH Installation Instruction for Economical Symmetric Floor-plate 2-post Lift
14
No
Material coding No Name
11MC126D
TLT235SB Powerside column
1
11MC124D
TLT240SB Powerside column
11MC127C
TLT235SB Offside column
2
11MC125C
TLT240SB Offside column
7 11MC045C
Floor plate
8 11MC044C
Floor plate cover
9
11MC544A
Top plate assembly
10
11AC082A
Nut M12
11
11BC111B
Top pulley
12
11AD096A
Bushing 2520
13
11AD223A
Retaining ring 25
14
11BE055B
Washer
17
11AD065A
Flat washer 12
18
11AD090A
Spring washer 12
19
11AB376A
Bolt M12×35
20
11AD056A
Flat washer 10
21 11AD116A
Spring washer 10
22
11AB375A
Bolt M10×25
23
11AJ072B
Steel cable
24 11AB969A
Anchor bolt M18×160
25 11BE108B
Cover of hose
26 11AB790A
Screw M5X12
27 11AD208A
Washer5
101
10AX459A
Power unit
102
11AJ435A
Fitting
103
12AE697A
HP hose
104 16BG076A
Flow control fitting
105
11AD099A
Seal14
106
11AD098A
Bushing 3052
107 12AE696A
HP hose
108
16BG078A
Main hydraulic cylinder
109 16BG079A
Auxiliary hydraulic cylinder
110 11BD281B
Sheave seat
111
11AD171A
Retaining ring 32
112
11AD092A
Retaining ring 30
