2 Lift Structure
The structure is as shown in Fig. 1:
Fig. 1
3840mm(151.2in)
SWI NG ARM
mi n110 mm(4.3in)
LI FTI NG PAD
POWERSI DE COLUMN
EXTENSI ON COLUMN
TOP BEAM
2750mm(108.3in)
OFFSI DE COLUMN
POWER UNI T
CONTROL BOX
ELECTROMAGNET
CARRI AGE
