- 11 -
ALARMS Key. Pressing ALARMS once displays the setpoint for Alarm 1. Pressing it
again displays the setpoint for Alarm 2. Pressing it again returns to the present value.
KEYS IN MENU MODE
Right Arrow Key (MENU). Pressing steps the meter through all menu items that
have been enabled and then back to the Run Mode. With the DC signal conditioner board
and no option boards, available menu items are _InPut, SEtuP, ConFG, _FiLtr, dEc.Pt,
SCALE, OFFst, Loc 1, Loc 2, Loc 3. If a change has been made to a menu item, that
change is saved to non-volatile memory when the key is pressed next, and StoreE is
displayed briefly.
To return the meter to the run mode after StoreE has been displayed, you can press the
key repeatedly to step through all top-level menu selections until rESEt is displayed
briefly. As a shortcut, to return to the run mode after StoreE has been displayed, you can
press then simultaneously. Again, rESEt will be displayed briefly.
Right Triangle Key (Digit Select).
• Pressing from the InPut menu brings up all meter functions available with the meter's
signal conditioner. For example, for the DC signal conditioner board, these are _dC U,
_dC A and _rAtio.
• Pressing from the SEtuP, ConfFG, FiLtr, SCALE, OFFSt, Loc 1, Loc 2 or Loc 3
menus items sequentially selects digit positions 1 - 5, as indicated by a flashing digit:
00000, 00000, 00000, 00000, 00000.
• Pressing from the dEC.Pt menu item sequentially selects decimal point positions,
which will flash: d.dddd dd.ddd ddd.dd dddd.d ddddd. .ddddd.
Up Triangle Key (Value Select). Pressing for a flashing item (digit position or decimal
point position) will increment that item. Pressing will save any changes, and StoreE
is displayed briefly.
Left Arrow Key (Reverse Menu). Pressing has the same effect as pressing ,
except that menu items are brought up in reverse order. Pressing repeatedly will
backtrack to the previous menu items all the way to meter rESEt and return to the run
mode.
