- 2 -
1. ORDERING GUIDE
Configure a model number in this format: L20201DCV1, CBL01
L…Digital panel meter with
screw terminal connectors.
Display Color
1 ............. DPM with green LED
2 ................. DPM with red LED
3 .... Extended DPM, green LED
4 ........ Extended DPM, red LED
Note: Extended adds rate of
change & linearization of non-
linear inputs. Not applicable to
thermocouple or RTD inputs.
Power
0 ..... 85-264 Vac or 90-300 Vdc
1 ......... 10-48 Vdc or 12-32 Vac
Setpoint Output
0 ...................................... None
1 ............ Two 8A contact relays
2 ............ Two solid state relays
3 ........... Four 8A contact relays
4 ............ Four solid state relays
Analog Output
0 ...................................... None
1 ..... 4-20 mA, 0-10V, -10/+10V
Digital Interface
0 ...................................... None
1 .................................... RS232
2 .................................... RS485
4 ...................... RS485-Modbus
5 ....................................... USB
6 ......... USB-to-RS485 gateway
7 ................................. Ethernet
8 ... Ethernet-to-RS485 gateway
Input Type
DC Volts
DCV1 ..................... 200.00 mV
DCV2 ........................ 2.0000 V
DCV3 ........................ 20.000 V
DCV4 ........................ 200.00 V
DCV5* ......................... 600.0 V
DCV6 .......................... 300.0 V
DC Amperes
DCA1 .................... 2.0000 mA
DCA2 .................... 20.000 mA
DCA3 .................... 200.00 mA
DCA4 ......................... 5.000 A
RTDs
P385C .. Pt100, -202 to 850°C
P385F ..Pt100, -331 to 1562°F
P392C. . Pt100, -202 to 850°C
P392F ..Pt100, -331 to 1562°F
N672C. ... Ni120, -80 to 260°C
N672F ... Ni120, -112 to 500°F
C427C. .... Cu10, -97 to 260°C
C427F .... Cu10, -143 to 500°F
Thermocouples
JC .................... -210 to 760°C
JF ................... -347 to 1400°F
KC ................. -244 to 1372°C
KF ................... -408 to 2501°F
TC .................... -257 to 400°C
TF ..................... -430 to 752°F
EC ................. -240 to 1000°C
EF ................... -400 to 1830°F
NC ................. -245 to 1300°C
NF ................... -410 to 2370°F
SC ................... -46 to 1768°C
SF ..................... -51 to 3214°F
RC ................... -45 to 1768°C
RF ..................... -49 to 3213°F
Resistance / Ohms
R0 ....... 0-2 ohms (fixed range)
R1 ...................0-20.000 ohms
R2 ...................0-200.00 ohms
R3 ................. 0-2.0000 kohms
R4 ................. 0-20.000 kohms
R5 ................. 0-200.00 kohms
R6 .... 0-2 Mohms (fixed range)
Process Signals
(4-20 mA, 0-10V, etc.)
P ............. 4-20 mA = 0-100.00
P1……………Custom Scaling
Specify min signal & reading,
max signal & reading.
RMS Volts
RMV1 .................... 200.00 mV
RMV2 ....................... 2.0000 V
RMV3 ....................... 20.000 V
RMV4 ....................... 200.00 V
RMV5* ....................... 600.0 V
RMV6 ......................... 300.0 V
RMS Amperes
RMA1.................... 2.0000 mA
RMA2.................... 20.000 mA
RMA3.................... 200.00 mA
RMA4......................... 5.000 A
Load Cells (6-wire ratio)
WM1….….-99,999 to +99,999
Specify min input signal & dis-
played reading, and max input
signal & displayed reading.
Full-scale inputs 20.000 mV to
500.00 mV, 10 Vdc excitation.
Options & Accessories
BL ......... Blank lens, no
button pads.
CBL01 .. RJ11-to-DB9 RS232
cable. Connects me-
ter to PC com port.
CBL02 .. USB-to-DB9 adap-
ter. For use with
CBL01.
CBL05 .. USB-cable. Type A
male to Type B
male.
IPC ........ NEMA-4 panel
cover.
BOX1 .... NEMA4 wall mount
enclosure.
BOX2 .... BOX1 plus IPC.
CASE1 .. Benchtop case for 1
meter.
CASE2 .. Benchtop case for 2
meters.
* Range not ETL certified
